Pneumatic speed controllers for cylinders in Odisha & Chhattisgarh
Flow control valves that set how fast cylinders and actuators move, for smoother motion and longer equipment life.
- Adjustable flow
- Built-in check valve
- Fits at the port
Get a quick quote
Share your requirement — we call back with options and price.
A pneumatic speed controller is a flow control valve with a built-in check valve. It restricts air flow in one direction and lets it pass freely in the other, so you can set how quickly a cylinder extends or retracts. Without speed control, cylinders slam into their end stops, damaging gates, dampers, mountings and the cylinder itself.
We supply in-line, banjo (elbow) and panel-mounted speed controllers in a range of port and tube sizes to plants and machine users in Odisha and Chhattisgarh, alongside pneumatic cylinders and valves. If you are looking for electric motor speed control, see our variable frequency drives.
On slide gates, dampers and diverters in steel, power and cement plants, uncontrolled cylinder speed is a common cause of broken linkages, bent rods and loosened mountings. Fitting and correctly setting speed controllers is one of the cheapest ways to extend the life of these mechanisms.
Where it is used
- Slide gates and flap gates
- Damper actuators
- Clamping and pressing
- Packaging and bagging machines
- Pneumatic doors and guards
- Diverter valves
Key benefits
Adjustable flow
Fine needle adjustment sets cylinder speed precisely.
Built-in check valve
Free flow one way, controlled flow the other.
Fits at the port
Banjo types screw directly into cylinder ports for compact installation.
Protects equipment
Reduces impact on gates, dampers and mountings.
Meter-out or meter-in?
For most double-acting cylinders, meter-out control is recommended: the controller restricts the air leaving the cylinder. This keeps the piston held between two air cushions and gives steady motion even when the load changes.
Meter-in control restricts air entering the cylinder. It is used for single-acting cylinders and some small-bore applications, but on double-acting cylinders it can cause jerky stick-slip motion.
| Type | Mounting | Typical use |
|---|---|---|
| Banjo / elbow | Screws into the cylinder port | Machines, compact installations, quick adjustment at the cylinder |
| In-line | Fitted in the tube or pipe run | Where the cylinder port is hard to reach |
| Panel or valve-mounted | On a panel or under the directional valve | Centralised adjustment on manifolds |
Selection and setting tips
- Port and tube size: match the cylinder port thread and the tube outside diameter.
- Flow capacity: a controller that is too small limits maximum speed even when fully open; check its flow rating against cylinder bore and speed.
- Setting: start with the needle nearly closed, then open slowly until the cylinder moves at the desired speed; lock the setting.
- Cushioning: speed controllers set travel speed; end-of-stroke cushioning in the cylinder protects the end stops.
- Dirty air: fine needle orifices can block; use filtered, dry air.
What to send us for a quote
Cylinder bore and port thread, tube size, meter-in or meter-out, mounting type, operating pressure, quantity, and the existing part number if replacing.
For plant-wide standardisation, we can recommend a small set of controller sizes that covers most of your cylinders, which simplifies spares.
Need help choosing?
Send us your application, duty and site conditions. We recommend the right model and quote with delivery to your plant.
Related
Speed Controllers we supply
Ask for a price on any item — we confirm availability and delivery to your site.
Speed Controllers: questions buyers ask
Straight answers to the questions plant teams ask us most.
Why does our cylinder move in jerks at low speed?
This is often stick-slip from meter-in control or from friction at very low speeds. Switch to meter-out control on both ports and check air quality and seal condition.
Do we need a speed controller on both cylinder ports?
For independent control of extend and retract speed on a double-acting cylinder, yes, fit one on each port set for meter-out.
Is a speed controller the same as a VFD?
No. A pneumatic speed controller regulates air flow to a cylinder. A VFD controls the speed of an electric motor; see our VFD pages for that.
Our cylinder became slow after a speed controller replacement. Why?
The new controller may have a lower flow capacity or be installed in the wrong direction. Check the flow direction arrow and compare the flow rating with the old unit.
Can speed controllers be used on vacuum lines?
Standard models are designed for positive pressure. Check the specification before using them on vacuum.
You may also need

Pneumatic Cylinder
Single and double acting cylinders in standard ISO dimensions, sized on force, stroke and mounting for gates, dampers and machines.
View details
Air Dryer
Refrigerated and desiccant dryers, sized on your compressor output and the dew point your equipment actually needs.
View details
2 Way Solenoid Valve
Normally closed and normally open on/off valves, matched to the medium, pressure, orifice and coil voltage.
View detailsGet smoother cylinder motion
Send cylinder port sizes and the number of controllers needed, and we will quote matching speed controllers.
